How to Program Radioddity GC-5 from The Keypad - Repeater Setting Guide
The
Radioddity GC-5 is rapidly gaining popularity among ham radio operators and
enthusiasts alike, thanks to its comprehensive features and cost-effective price
point. This model is particularly appealing because it allows for manual
programming without the need for a PC, making it an excellent choice for both
seasoned ham radio operators and beginners.
In this article, we will walk you through the steps of setting up a repeater
channel using the keypad, showcasing the ease and convenience of programming
this device. Whether you’re a seasoned ham radio operator or just starting out,
the Radioddity GC-5 offers a user-friendly experience that doesn’t compromise on
functionality.
To enter a channel from the front panel, the steps below should help:
• The Menu(Green) key is used to invoke the Menu system, Enter the selection
part of an option, and Confirm that option.
• The Back (Red) key is used to exit a Menu option (or it will automatically
return after a short delay)
Once the repeater Receive frequency is entered via the VFO Mode and using the
Keypad, the Menu options will help you set the other parameters.
Program Example:
- 2m Repeater
- 146.685 Receive frequency
- The offset is .6 MHz
- Shift Direction is - (minus)
- Transmit CTCSS Tone is 100 Hz
- Receive CTCSS Tone is 100 Hz
Step 1: Program Frequency
Enter VFO (Frequency) Mode using VFO/MR key.
Use the Keypad to enter 145685 (the Decimal Point and extra 2 Zeros will be
added automatically)
Step 2: Program Transmit Power
Press Menu, Option 2 TX power
Press Menu to Select
Use Up/Down Arrows as needed to select the Power setting
Press Menu to Confirm
Exit to Return (or scroll to the next Option)
Step 3: Program TX CTCSS Tone
Press Menu, then 1 2 to set TX CTCSS tone
Press Menu to Select
Use Up/Down Arrow as needed to scroll to 100.0 Hz, or press the first 3 digits
(1 0 0), scroll to 100.0 Hz
Press Menu to Confirm
Exit to Return (or scroll to the next Option)
Step 4: Program RX CTCSS Tone
Press Menu, then 1 0 to set RX CTCSS tone
Press Menu to Select
Use Up/Down Arrow as needed to scroll to 100.0 Hz, or press the first 3 digits
(1 0 0), Scroll to 100.0 Hz
Press Menu to Confirm
Exit to Return (or scroll to the next Option)
Step 5: Program Shift Direction
Press Menu, then 2 8 to set Shift Direction
Press Menu to Select
Use Up/Down Arrows as needed to scroll to Minus
Press Menu to Confirm
Exit to Return (or scroll to the next Option)
Step 6: Program Frequency Offset
Press Menu, then 2 9 to set the Frequency Offset
Press Menu to Select
Enter 000600 (The decimal point is automatically inserted after the 3rd digit is
entered.)
Press Menu to Confirm
Exit to Return (or scroll to the next Option)
Step 7: Store The Setting
Press Menu, then 3 0 to set the Channel to store the settings
Press Menu to Select
Use Up/Down arrows as needed to find a blank (unused) Channel.
Channels that have been used to store memory will have CH preceding the number.
Press Menu to Confirm (when a blank channel number had been selected)
Voice Prompt: Receiving Memory
Exit to Return
Note:
1. Once Menu is pressed, you can use the Up/Down arrows to scroll through the
settings, or directly address them using a 2-digit selection.
2. Additional settings can be selected as needed prior to storing the channel.
3. If a setting needs to be altered after the channel is stored, the channel
will need to be deleted using Menu option 31, then saved to the same channel
using the additional options.
If you encounter any issues with this radio or the guidance provided, please
don't hesitate to
reach out
to us. Our technical support team is always ready to assist you. We’re
committed to ensuring that your experience with the Radioddity GC-5 is as smooth
and enjoyable as possible.
Enjoy your radio!
